XZ13600 HDD is a kind of modular combined split type rig and adopts advanced and proprietary technologies such as electro-hydraulic proportional control and load-sensitive control. The main performance parameters and control technologies have reached the international advanced level. The main components of hydraulic system and other systems are all of world-famous brands with reliable quality.

Highlights Introduction

1. The digital display system directly displays the main construction parameters such as rotation torque and push-pull force, which overcomes the shortcoming that the traditional drilling machine used pressure gauge needs conversion, and the operation is simple.

2. The power head rotation torque and push-pull force overload protection system adopts electronic sensing with rapid response and high reliability. The rotation torque and push-pull force can be accurately preset. The power head spindle floating reliably protects the drill pipe thread to improve the service life of drill pipe.

3. The four-engine power system adopts Cummins EFI engines. The start of any engine can complete all the actions of the whole machine and it can realize the multi-engine combination technology. Equipped with multi-gear stepless speed regulation technology, it can adapt to a wide geological range and has low construction cost.

4. The sliding of the drilling frame relies on the push-pull by cylinder and the double-variable angle adjustment mechanism makes the adjustment of the penetrating angle simple, convenient and safe.

5. Vise with eight cylinders in two sets ensures the reliable clamping of drill pipe and large screw off torque. The vise floats all the way, which is convenient for the casing construction.

6.With multi-pump joint and splitting flow control technology, high engine power utilization saves energy and fuel.
 It adopts multiple advanced energy-saving control technologies such as electro-hydraulic proportional control and so on. Imported hydraulic and electrical components are of reliable quality.

7.  Modular combination and disassembly transportation technology makes it possible for the chassis, drilling frame and power head to be dismantled and transported. The power station and the operating room meet the container transportation specifications, making the transportation convenient and the cost low.
